Dimensions: Ø 25mm (Diameter) x 8mm (Thickness), Ø 5.5mm (Countersunk hole diameter) The dimensions of the product are measured in metric units, with an approximate “tolerance” (manufacturing margin of error) of +/- 0.05mm
Pull Strength: 14kg The approximate force (in metric units) required to remove a magnet from industry-standard 3mm thick mild steel. These “strengths” are measured using mathematical calculations, and should be used as a general guide only.
Direction of Magnetism:”Axially” magnetised (top to bottom) thru 8mm thickness.The axis through which a product is magnetised. Products may be magnetised axially, diametrically or otherwise (e.g. multipole). See more about directions of magnetism at our Help Centre.
Features:- Magnet is encapsulated on all but one side with a protective steel holding pot.- Incorporates a countersunk hole for use with flathead screws.- Powerful Rare Earth (Neodymium) permanent magnet.- High gloss Nickel coating, for protection against corrosion.- Maximum operating temperature 80°C / 100°C
